Preface
Instrument Options
The WFM6120, WFM7020, and WFM7120 ship with support for monitoring standard definition (SD) serial digital signals. The
following options are available for purchase with the indicated instrument models. You can verify which options are installed
on your instrument after power-up by pressing the CONFIG button and looking under the View HW/SW Options submenu.
Option
Instrument Description
3G
WFM7020
WFM7120
Adds support for monitoring of 3 Gbps single link SDI signals,
either Level A or Level B, in the following formats: 1920 x
1080p/50/59.94/60. (Requires Option HD.)
Option 3G cannot be installed simultaneously with Options
EYE or PHY.
JIT WFM7120
Adds jitter measurement and jitter waveform capabilities for
3Gbps single link SDI signals. Includes 3Gbps single link SDI
generator output capabilities. (Requires Option 3G.)
DL WFM7020
WFM7120
Adds dual link (DL) support. Dual link allows for the reception
of two SDI input signals (Link A and Link B) at the same time.
Information from each link is combined and shown on a single
display. Supports all 10 bit and 12 bit YCbCr and RGB formats.
Supports 2048 x 1080 12 bit XYZ formats. Requires Option HD.
SIM
WFM7120
Adds simultaneous input monitoring (SIM) support. SIM
allows for m onitoring of two different input signals at the same
time. Information from each input is displayed separately
in two FlexVuTM tiles (vertically). Supports SDI-SDI and
SDI-Composite input combinations only.
SD
WFM6120
WFM7020
WFM7120
Adds support for standard definition (SD) serial digital
monitoring; two SD-SDI inputs. Standard for all listed
instruments.
HD WFM7020
WFM7120
Adds support for high definition (HD) serial digital monitoring;
two HD-SDI inputs.
CPS
WFM6120
WFM7020
WFM7120
Adds support for composite (CPS) analog video monitoring
(NTSC and PAL); two passive loop-through inputs; two
composite analog inputs.
ALOG
WFM6120
WFM7020
WFM7120
Adds Audio Loudness Session Display with Trend Chart and
Audio Loudness data saving capability. Requires Option AD,
Option DDE, Option BAS, or Option ALY to already be installed.
AD WFM6120
WFM7020
WFM7120
Adds support for digital audio monitoring, and analog audio
and digital audio in embedded and AE S/EBU formats; two sets
of six channels of analog audio inputs; eight channels analog
audio outputs.
DPE WFM7120
Adds option AD capabilities (Analog and Digital A udio –
Embedded or External AES), plus support for decoding and
monitoring Dolby E, D olby Digital Plus, and Dolby D Audio.
DDP WFM7120
Adds support for decoding and monitoring Dolby Digital Plus
Audio for instruments a lready equipped with Option DDE.
AVD WFM7120
Adds support for Audio/Video delay (AVD) measurement.
xii Waveform Monitors Quick Start User Manual
