Monitoring Audi
o
Quick Selection of 1-8 or 9-16 Channels of Embedded Audio
1. Select a tile.
2. Press and hold
the Audio button to open
the Audio display in a tile and pop up the
Audio menu.
3. Use the arrow keys and SEL button to
make selections in the steps that follow.
4. Select Audio Input and then select
Emb. 1-8 as shown.
You can either select Emb. 1–8 or
Emb. 9–16 display.
102 Waveform Monitors Quick Start User Manual
