Monitoring Clos
ed Captioning (CC), Teletext, AFD, and Safe A rea Compliance
Teletext B Settings
14. Select Teletext B Settings from the Aux
Data Settings submenu.
15. Select Teletext Required and then
select Yes or
No, depending on whether
or not you w ant to monitor for required
settings.
16. Select WST Transport, and then
select from
Auto, VBI, OP47 (SDP), or
OP47 (Multi). If you select Auto,the
instrument will search for any available
transport
.
17. If require
d services is s et to Yes, select
Teletext Req Pages and press the SEL
button.
18. When Teletext Required Pages dialog
box appears, use the General knob to
navigat
e to the box in the Allo w Alarm
column that is next to the page for which
you want monitor.
19. Press the SEL button to mark the box.
20. P ress the right arrow key and then press
the SEL
button to highlight the Page
Number box.
21. Use the General knob to set the box
to the desired page number, and then
press
the SE L button.
22. When y
ou are finished with your
selections, use the down arrow to
navigate to the Return box, and then
pres
stheSE L button.
To View Closed Captioning Status
and S
ubtitles
1. Press the STATUS button to select the
Status display mode.
2. Press and hold the STATUS button to
display the pop-up menu.
118 Waveform Monitors Quick Start User Manual
