Tektronix WVR6020 Quick Start Manual

Getting Acquain
tedWithYourInstrument
Remote Connector and Pin Out
The Remote connector interface uses ground closures for remote control and to indicate to external equipment when alarms
have occurred. The Remote connector is a 15-pin D-type connector w ith socket contacts.
NOTE. For connection and operation of Preset Recall, see the Technical Reference on the Product D ocumentation CD
that shipped with your instrument.
Hex
Binary Pins
15, 14, 13, 5
Direct mode
selection
Encoded
mode
selection
F 1111 None No action
E 1110 Preset 1
CPS B
D 1101 Preset 2
CPS A
C
1100
SDI B
B 1011 Preset 3
SDI A
A 1010
Channel B
9 1001
Channel A
8 1000
7
0111 Preset 4
60110 Factory
Preset
5
0101 Preset 5
4 0100 Preset 4
3 0011 Preset 3
2 0010 Preset 2
1 0001 Preset 1
0 0000 Unused
Waveform Rasterizers Quick Start User Manual 21
