Bandwidth 802.11n: 20/40 MHz
802.11ac: 20/40/80 MHz
802.11ax: 20/40/80 MHz
Antenna
Integrated directional dual-band MIMO array
A.5.6 Configuration interface
LOCAL TERMINAL RS-232 115200-8-N-1 without flow control.
CONNECTOR RJ45 female on the rear panel.
A.5.7 Power supply
INPUT VOLTAGE +12V DC.
INPUT CURRENT 2.5 A.
CONNECTOR Jack 5.5/2.5 mm.
A.5.8 Dimensions and weight
TYPE Desktop / chassis for a 1 U high Rack mount enclosure.
DIMENSION 283mm x 144mm x 40mm
WEIGHT 0.6 Kg
A.5.9 Environmental specifications
TEMPERATURE OPERATING NORMALLY: 0 ºC to 45 ºC.
STORED: -25 ºC to 70 ºC.
RELATIVE HUMIDITY 10 % to 95 %.
NOISE 38.3 dB SPL (5000 rpm).
Technical Information Teldat S.A.
26 Teldat Connect-FW
