Teldat RS123 Seies User Manual

A.6.6 Wireless LAN interface
WLAN standards 802.11n (MIMO 2x2); 802.11b; 802.11g; 802.11a; 802.11h.
Frequency bands 2.4 GHz in-
door and outdoor (EU)
2400–2483.5 MHz: 20 dBm max EIRP allowed.
Frequency bands 2.4 GHz in-
door and outdoor (USA)
2400–2473 MHz: 20 dBm max EIRP allowed.
Frequency bands 5 GHz indoor
(EU), indoor and outdoor (USA)
5170-5330 MHz: 23 dBm max EIRP allowed
Frequency bands 5 GHz indoor
and outdoor (EU/USA)
5490-5710 MHz: 30 dBm max EIRP allowed
Frequency bands 5 GHz indoor
and outdoor (USA)
5735-5835 MHz: 30 dBm max EIRP allowed
WLAN modes 2.4 GHz: 802.11b only; 802.11g only, 802.11b/g/n mixed; 802.11b/g/n mixed long;
802.11b/g/b mixed short; 802.11b/g/n; 802.11g/n; 802.11n only; 5 GHz Operation:
802.11a only; 802.11a/n; 802.11n only.
Automatic Rate Selection (ARS) Automatic usage of the optimized data rate.
Data rates for 802.11b,g (2.4
GHz)
11, 5.5, 2 and 1 Mbps (DSSS modulation).
54, 48, 36, 24, 18, 12, 9 and 6 Mbps (OFDM modulation).
Data rates for 802.11a,h (5
GHz)
54, 48, 36, 24, 18, 12, 9 and 6 Mbps (OFDM modulation).
Data rates for 802.11n, Long
Guard (800ns), 20 MHz
MSC0 6,5 Mbps; MSC1 13 Mbps; MCS2 19,5 Mbps; MCS3 26 Mbps; MCS4 39
Mbps; MSC5 52 Mbps; MCS6 58,5 Mbps; MCS7 65 Mbps; MCS8 13 Mbps; MCS9
26 Mbps; MCS10 39 Mbps; MCS11 52 Mbps; MCS12 78 Mbps; MCS13 104
Mbps; MCS14 117 Mbps; MCS15 130 Mbps.
Data rates for 802.11n, Short
Guard (400ns), 20 MHz
MSC0 7,2 Mbps; MSC1 14,4 Mbps; MCS2 21,7 Mbps; MCS3 28,9 Mbps; MCS4
43,3 Mbps; MSC5 57,8 Mbps; MCS6 121,5 Mbps; MCS7 135 Mbps; MCS8 27
Mbps; MCS9 54 Mbps; MCS10 81 Mbps; MCS11 108 Mbps; MCS12 162 Mbps;
MCS13 216 Mbps; MCS14 243 Mbps; MCS15 270 Mbps.
Data rates for 802.11n, Long
Guard (800ns), 40 MHz
MSC0 13,5 Mbps; MSC1 27 Mbps; MCS2 40,5 Mbps; MCS3 54 Mbps; MCS4 81
Mbps; MSC5 108 Mbps; MCS6 121,5 Mbps; MCS7 135 Mbps; MCS8 27 Mbps;
MCS9 54 Mbps; MCS10 81 Mbps; MCS11 108 Mbps; MCS12 162 Mbps; MCS13
216 Mbps; MCS14 243 Mbps; MCS15 270 Mbps.
Data rates for 802.11n, Short
Guard (400ns), 40 MHz
MSC0 15 Mbps; MSC1 30 Mbps; MCS2 45 Mbps; MCS3 60 Mbps; MCS4 90
Mbps; MSC5 120 Mbps; MCS6 135 Mbps; MCS7 150 Mbps; MCS8 30 Mbps;
MCS9 60 Mbps; MCS10 90 Mbps; MCS11 120 Mbps; MCS12 180 Mbps; MCS13
240 Mbps; MCS14 270 Mbps; MCS15 300 Mbps.
Output power limitation (without
antenna gain)
Adjustable in the following steps: 5, 8,11,14,16 dBm and maximum. Maximal
power varies depending on data rate, frequency band and country setting.
Bandwidth (802.11n) 20/40 MHz (bundling two adjoining 20 MHz channels into one 40 MHz channel).
CONNECTOR Two SMA-RP male connectors.
Teldat S.A.
Technical Information
RS123 Router 29
