A.6.7 USB interface
3G USB MODEMS Please visit the Teldat website at http://www.teldat.com to get a list of the suppor-
ted 3G USB modems.
SPEED The interface complies with the USB 2.0 (480 Mbps) standard; the end speed de-
pends on the 3G USB modem used.
CONNECTOR USB Type A.
A.6.8 Configuration interface
MODE 115200-8-N-1 without flow control.
CONNECTOR USB Type B.
A.6.9 Power supply
INPUT VOLTAGE 110 - 240 V AC.
FREQUENCY 50 - 60 Hz.
INPUT CURRENT 0.7 A.
CONNECTOR IEC C6.
A.6.10 Dimensions and weight
TYPE Metallic housing with optional mounting in a 19-inch rack (bracket option).
LENGTH x WIDTH x HEIGHT 265mm x 170mm x 40mm.
WEIGHT 1.4 kg.
A.6.11 Environmental specifications
TEMPERATURE OPERATING NORMALLY: 0 ºC to 40 ºC.
STORED: -25 ºC to 70 ºC.
RELATIVE HUMIDITY On: 10 % to 90 %, non-condensing.
Technical Information Teldat S.A.
30 RS123 Router
