USA: 802.11n-HT40: 5190~5230 MHz (channels 38 and 46), 5270~5310 MHz
(channels 54 and 62), 5510~5670 MHz (channels 102 to 134), 5755~5795
(channels 151 and 159) ;
Carrier frequencies stability
+- 2 ppm
Number of Channels EU: 802.11a/n-HT20: 19
EU: 802.11n-HT40: 9
USA: 802.11a/n-HT20: 24
USA: 802.11n-HT40: 11
Type of modulation
802.11b: PSK, DBPSK, DSSS, and CCK
802.11g: BPSK, QPSK, 16QAM, 64QAM with OFDM
802.11a: BPSK, QPSK, 16QAM, 64QAM with OFDM
802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
Transmission technology
CSMA/CA (Carrier-sense multiple access with collision avoidance)
Unwanted Emissions in the
Spurious Domain Limit
1 GHz to 12,75 GHz < -30 dBm according to EN 301 893 and EN 300 328
TX power @ 2,4 GHz 802.11n
40 MHz (HT40)
MCS0/8 19 dBm; MCS1/9 19 dBm; MCS2/10 19 dBm; MCS3/11 19 dBm;
MCS4/12 19 dBm; MCS5/13 19 dBm; MCS6/14 19 dBm; MCS7/15 19 dBm.
Receiver Sensitivity @ 2.4 GHz
802.11n 40 MHz (HT40)
MCS0 -92 dBm; MCS1 -91 dBm; MCS2 -89 dBm; MCS3 -86 dBm; MCS4 -82
dBm; MCS5 -79 dBm; MCS6 -77 dBm; MCS7 -75 dBm; MCS8 -91 dBm; MCS9 -
91 dBm; MCS10 -89 dBm; MCS11 -85 dBm; MCS12 -82 dBm; MCS13 -78 dBm;
MCS14 -77 dBm; MCS15 -74 dBm.
Receiver Sensitivity @ 5 GHz
802.11n 40 MHz (HT40)
MCS0 -91 dBm; MCS1 -89 dBm; MCS2 -87 dBm; MCS3 -84 dBm; MCS4 -81
dBm; MCS5 -78 dBm; MCS6 -76 dBm; MCS7 -74 dBm; MCS8 -90 dBm; MCS9 -
89 dBm; MCS10 -87 dBm; MCS11 -83 dBm; MCS12 -80 dBm; MCS13 -77 dBm;
MCS14 -75 dBm; MCS15 -73 dBm.
Receiver Sensitivity @ 5 GHz
802.11a/h
6 Mbps -95 dBm;9 Mbps -94dBm; 12 Mbps -93 dBm; 18 Mbps -90 dBm; 24 Mbps
-88 dBm; 36 Mbps -84 dBm; 48 Mbps -82 dBm; 54 Mbps -81 dBm.
TX power @ 2,4 GHz 801.11b/g 1 Mbps 19 dBm; 2 Mbps 19 dBm; 5,5 Mbps 19 dBm; 11 Mbps 19 dBm; 6 Mbps 19
dBm;9 Mbps 19 dBm; 12 Mbps 19 dBm; 18 Mbps 19 dBm; 24 Mbps 19 dBm; 36
Mbps 19 dBm; 48 Mbps 19 dBm; 54 Mbps 19 dBm.
TX power @ 2,4 GHz 802.11n
20 MHz (HT20)
MCS0/8 19 dBm; MCS1/9 19 dBm; MCS2/10 19 dBm; MCS3/11 19 dBm;
MCS4/12 19 dBm; MCS5/13 19 dBm; MCS6/14 19 dBm; MCS7/15 19 dBm.
Receiver Sensitivity @ 2.4 GHz
802.11b/g
1 Mbps -92 dBm; 2 Mbps -92 dBm; 5,5 Mbps -92 dBm; 11 Mbps -92 dBm; 6 Mbps
-95 dBm;9 Mbps -95 dBm; 12 Mbps -94 dBm; 18 Mbps -92 dBm; 24 Mbps -90
dBm; 36 Mbps -85 dBm; 48 Mbps -83 dBm; 54 Mbps -80 dBm.
TX power @ 5 GHz 802.11n 40
MHz (HT40)
MCS0/8 19 dBm; MCS1/9 19 dBm; MCS2/10 19 dBm; MCS3/11 19 dBm;
MCS4/12 19 dBm; MCS5/13 18 dBm; MCS6/14 17 dBm; MCS7/15 17 dBm.
TX power @ 5 GHz 802.11n 20
MHz (HT20)
MCS0/8 23 dBm; MCS1/9 23 dBm; MCS2/10 22 dBm; MCS3/11 21 dBm;
MCS4/12 20 dBm; MCS5/13 19 dBm; MCS6/14 18 dBm; MCS7/15 18 dBm.
TX power @ 5 GHz 801.11a/h MCS0 -95 dBm; MCS1 -94 dBm; MCS2 -92 dBm; MCS3 -88 dBm; MCS4 -85
dBm; MCS5 -81 dBm; MCS6 -80 dBm; MCS7 -78dBm; MCS8 -95 dBm; MCS9 -94
Teldat S.A.
Radio Information
RS123 Router 33

Teldat RS123 Seies Specifications

General

Brand	Teldat
Model	RS123 Seies
Category	Network Router
Language	English
