TCM260904 Rev 0.1
TCM260904 Page 17 of 31
EAST/WEST PUSHBUTTON FUNCTION SETTING:
Item Title Options Description
A Interlock 1. Interlock
2. Non-Interlock
“Interlock”: If the motions cannot be operated
simultaneously then select “Interlock”.
“Non-Interlock”: If the motions are allowed to operate
simultaneously then select “Non-Interlock”.
This item is selectable only when East and West
pushbuttons are set at “Normal” function.
East: West:
1. Normal Normal
2. Toggle Normal
3. Toggle Toggle
4. On Off
B Function
“Normal”: The associated relay is “on” when the
pushbutton is pressed and held, and is “off” when the
pushbutton is released.
“Toggle”: Press the pushbutton and release once for “on”,
re-press and release for “off”.
“ON & OFF”: The two pushbuttons are set to
respectively control the same relay. If a pushbutton set as
“on” is pressed and released, then the relay remains
closed. No other pushbutton can change the status of this
relay except the pushbutton set as “off”.
SOUTH/NORTH PUSHBUTTON FUNCTION SETTING:
Item Title Options Description
A Interlock 1. Interlock
2. Non-Interlock
“Interlock”: If the motions cannot be operated
simultaneously then select “Interlock”.
“Non-Interlock”: If the motions are allowed to operate
simultaneously then select “Non-Interlock”.
This item is selectable only South and North pushbuttons
are set at “Normal” function.
South: North:
1. Normal Normal
2. Toggle Normal
3. Toggle Toggle
B Function
4. On Off
“Normal”: The associated relay is “on” when the
pushbutton is pressed and held, and is “off” when the
pushbutton is released.
“Toggle”: Press the pushbutton and release once for “on”,
re-press and release for “off”.
“ON & OFF”: The two pushbuttons are set to
respectively control the same relay. If a pushbutton set as
“on” is pressed and released, then the relay remains
closed. No other pushbutton can change the status of this
relay except the pushbutton set as “off”.
