TCM260904 Rev 0.1
TCM260904 Page 18 of 31
R1/R2PUSHBUTTON FUNCTION SETTING:
Item Title Options Description
A Interlock 1. Interlock
2. Non-Interlock
“Interlock”: If the motions cannot be operated
simultaneously then select “Interlock”.
“Non-interlock”: If the motions are allowed to operate
simultaneously then select “Non-Interlock”.
This item is selectable only when R1 and R2 pushbuttons
are set at “Normal” function.
R1: R2:
1. Normal Normal
2. Toggle Normal
3. Toggle Toggle
B Function
4. On Off
“Normal”: The associated relay is “on” when the
pushbutton is pressed and held, and is “off” when the
pushbutton is released.
“Toggle”: Press the pushbutton and release once for “on”,
re-press and release for “off”.
“ON & OFF”: The two pushbuttons are set to
respectively control the same relay. If a pushbutton set as
“on” is pressed and released, then the relay remains
closed. No other pushbutton can change the status of this
relay except the pushbutton set as “off”.
R3/R4 PUSHBUTTON FUNCTION SETTING:
Item Title Options Description
A Interlock 1. Interlock
2. Non-Interlock
“Interlock”: If the motions cannot be operated
simultaneously then select “Interlock”.
“Non-interlock”: If the motions are allowed to operate
simultaneously then select “Non-Interlock”.
This item is selectable only R3 and R4 Pushbuttons are set
at “Normal” function.
R4: R3:
1. Normal Normal
2. Toggle Normal
3. Toggle Toggle
B Function
4. On Off
“Normal”: The associated relay is “on” when the
pushbutton is pressed and held, and is “off” when the
pushbutton is released.
“Toggle”: Press the pushbutton and release once for “on”,
re-press and release for “off”.
“ON & OFF”: The two pushbuttons are set
To respectively control the same relay. If a pushbutton set
as “on” is pressed and released, then the relay remains
closed. No other pushbutton can change the status of this
relay except the pushbutton set as “off”.
To Next Page
