Dual-Feed 200A 4/5 TPA/GMT Fuse Alarm Panel
Power :: 009-8005-0404 :: 009-8005-0404G :: 009-8005-0404L
1.4.1 Compression Lugs
Table 1 - Input Power Lugs (1⁄4 in. Dual Holes on 3⁄4 in. Centers, Uninsulated)
Item 2 AWG 1 AWG 1/0 AWG 2/0 AWG 3/0 AWG
T&B 54208-0416
(Die Code 37)
54255-0416
(Die Code 42)
54210-0416
(Die Code 45)
54211UB-0416
(Die Code 50)
Burndy YA2CL2TC14 E2
(Die Code 10)
YA1CL2TC14E 2
(Die Code 11)
YA25L2TC14E2
(Die Code 12)
YA26L2TC14E2
(Die Code 13)
YA27L2TC14E2
(Die Code 13)
Panduit LCD2-14B-Q
(Die Code 33)
LCD1-12B-E
(Die Code 37)
LCD1/0-14B-X
(Die Code 42)
LCD2/0-14B-X
(Die Code 45)
LCD3/0-14B-X
(Die Code 50)
Table 2 - Ground Lugs (1⁄4 in. Dual Holes on 5/8 in. Centers, Uninsulated)
Item 6 AWG 4 AWG
T & B 54205 (Die Code 24) 54206 (Die Code 29)
Burndy YA6CL2TC14 (Die Code 7) YA4CL2TC14 (Die Code 8)
Panduit LCD6-14A-L (Die Code 24) LCD4-14A-L (Die Code 29)
Table 3 - TPA Output Ring Lugs
(#10 Screw Terminals, Nylon Insulated Except Where Noted)
Item 14 AWG 12 AWG 10 AWG 8 AWG
AMP 36160 35109 35109 324043
Burndy YAE12NBOX YAE12NBOX YAV10BOX YA8CLBOX (Uninsulated)
(Die Code 21)
Panduit LCA10-10-L LCA10-10-L LCA10-10-L LCA8-10-L (Uninsulated)
(Die Code 21)
Table 4 - GMT Output Ring Lugs (#6 Screw Terminals, Nylon Insulated)
Item 26 AWG 22 AWG 20 AWG 16 AWG 14 AWG
AMP 152658
Burndy YAE22N66FBOX YAE18N25BOX YAE14N76FBOX YAE12N1BOX
