Dual-Feed 200A 4/5 TPA/GMT Fuse Alarm Panel
Power :: 009-8005-0404 :: 009-8005-0404G :: 009-8005-0404L
1.6 Assembly Drawings
#10 - 32 Stud & Nut (Use 3/8" Socket)
1/4 - 20 Stud
#6 Panhead
NOTES:
1. Dimensions are in or in. (cm)
(cm)
in.
2. Panel not supplied with fuses.
REAR VIEW
(ROTATED)
TOP VIEW
FRONT VIEW
Universal Bracket Reversed for 23" Rack
Holes Accommodate
EIA/WECO Mounting Patterns
Pull-Out Designation Card Below
Replacable Alarm Board
1.72
(4.37)
1.00
(2.54)
23.00 (58.42)
22.31 (56.67)
19.00 (48.26)
18.31 (46.51)
17.25 (43.82)
11.86
(30.14)
0.10
(0.25)
1.00
(2.54)
2.00
(5.08)
1.00
(2.54)
0.39 (0.98)
10.01
(25.42)
1.15
(2.92)
T
P
A
P
A
T
GMT GMT
0.75
(1.90)
0.46
(1.17)
0.32
(0.81)
1/4 - 20 Hexhead Bolt
(Use 7/16" Socket)
0.625
(1.59)
SIDE VIEW
(DETAIL)
1.00
[2.54]
Lug width
Applies to: 009-8005-0404
