Dual-Feed 200A 4/5 TPA/GMT Fuse Alarm Panel
Power :: 009-8005-0404 :: 009-8005-0404G :: 009-8005-0404L
GMT Outputs Specications
Max. GMT Output Fuse (ea.)
009-8005-0404 and 009-8005-0404L
009-8005-0404G
15A
20A
Max. GMT Output Load (ea.) - continuous
009-8005-0404 and 009-8005-0404L
009-8005-0404G
10.5A
14A
Max. Total GMT Output Load 65A per side
Short circuit withstand rating 450A
GMT Output Terminal (wire binding) 20, #6 panhead screws (max lug width of .32 in.
[.81 cm])
GMT Output Wire Size #20 to #12 AWG (depends on output fuse rating)
Grounding Specications
Earth GND Terminal Studs (with split ring lock
washers & hex nuts) for dual-hole compression lug
Dual 1/4"-20 threaded holes on 5/8 in. (1.59 cm)
centers. Torque supplied bolt (using 7/16 in. or 12 mm
socket) to 45 in.-lb (5 N•m)
Ground Wire Size Up to #4 AWG (depends on input interrupt device)
Alarms Specications
Alarm Relay Contacts 2A @ 30 Vdc
0.6A @ 60 Vdc
Max. Alarm Card Power Rating @20V: 85 mA (1.70W)
@24V: 103 mA (2.47W)
@27V: 109 mA (2.94W)
@30V: 112 mA (3.36W)
@42V: 123 mA (5.17W)
@48V: 128 mA (6.14W)
@56V: 135 mA (7.56W)
@60V: 139 mA (8.34W)
009-8005-0404 and 009-8005-0404L: 8W
009-8005-0404G: 2W
Alarm Wire Size #24 AWG, typ (#26 to #20 AWG)
Indicators Specications
INPUT POWER LEDs (Green) Lights when power is applied to that feed
FUSE ALARM LED (Red) Lights if any GMT fuse blows
