Teledyne 8800A - Appendix C: Sensor Mechanical

8800 Series Trace Moisture Analyzer Instruction Manual Appendices
40
Appendix C: Sensor Mechanical
flats for 1 " wrench
1
4
/
~1.45"
14mm x 1.25mm
3/4"-16
Viton A O-ring
female BNC connector
2.230"
3" min
Removable Sensor encapsulated
in 100
sintered stainless steel,
unscrew to remove.
5/16"-24
tension washer
H
P
C
-
5
0
0
P
LISTED
76NM
cable with molded-on
male BNC connector
