8 Linea 2K and 4K Monochrome Line Scan Camera User's Manual
03-032-20206-00 Teledyne DALSA
Models and Accessories
Table 1: Camera Models Comparison
Linea Dual Line Model Comparison
Camera
Part Number
Resolution
Max. Line Rate
Pixel Size
Linea 2K CL
LA-CM-02K08A-00-R
2048 x 1
80 kHz
7.04 µm x 7.04 µm
Linea 4K CL
LA-CM-04K08A-00-R
4096 x 1
80 kHz
7.04 µm x 7.04 µm
Table 2: Optional Lens Mount Accessories
Part No.
Description
AC-LC-00001-00-R
M42 x 1 to C-mount adapter 12 mm BFD lens
AC-LA-00115-A0-R
M42 x 1 to F-mount adapter 12 mm BFD lens, heavy duty with clip
AC-MS-00108-01-R
Heat sink (LA 4K / 2K)
Table 3: Software
Software
Product Number / Version Number
Camera firmware
Embedded within camera
GenICam™ support (XML camera description file)
Embedded within camera
Sapera LT, including CamExpert GUI application and
GenICam for Camera Link imaging driver
Version 7.30 or later
Camera Performance Specifications
Table 4: Camera Performance Specifications
Specifications
Performance
Imager Format
High speed CMOS line scan
Resolution
2048 or 4096 pixels
Pixel Size
7.04 µm x 7.04 µm
Pixel Fill Factor
100 %
Line Rate
Up to 80 kHz
Exposure Time
4 µs to 3 ms
Bit Depth
8 bit or 12 bit, selectable
Connectors and Mechanicals
Control & Data Interface
Base, Medium, and Full Camera Link configurations (2 x SDR-26)
Power Connector
Hirose 6-pin male circular
Power Supply
+ 5 V to + 24 V DC (+4.8 V to +25.2 V maximum limits)
Power Dissipation
< 4.5 W
Size
62 mm (W) x 62 mm (H) x 31 mm (D)
Mass
< 190 g
Operating Temp
0 °C to 65 °C, front plate temperature
Optical Interface
Lens Mount
M42 x 1, C-mount adapter available
Sensor to Camera Front Distance
12 mm
Sensor Alignment (aligned to sides of camera)
