Teledyne Linea - Certifications and Compliance; Supported Industry Standards

Linea 2K and 4K Monochrome Line Scan Camera User's Manual 9
Teledyne DALSA 03-032-20206-00
 y (parallelism)
x
y
z
 z
0.08° or 100 µm
± 300 µm
± 300 µm
± 300 µm
± 0.3°
Compliance
Regulatory Compliance
CE, FCC, and RoHS; GenICam
Operating Ranges
Performance
Notes
Dynamic Range
> 60 dB
Random Noise
< 3.75 DN* rms
FFC enabled
Broadband Responsivity
320 DN / (nJ / cm
2
)
Gain
1x to 10x Nominal range
DC Offset
7 DN
FFC enabled
PRNU
< 1.5% @ 50% Sat
FPN
< 7 DN
SEE
12.5 nJ / cm
2
NEE
11.7 pJ / cm
2
Antiblooming
> 100 x Saturation
Integral non-linearity
1.5 % DN
*DN = digital number
Test Conditions:
 Values measured using 12-bit, 1x gain.
 10 kHz line rate
 Light source: broadband, quartz halogen, 3250 K with 700 nm IR cut-off filter.
 Front plate temperature: 45º C
Certifications and Compliance
Compliance
EN 55011, FCC Part 15, CISPR 11, and ICES-003 Class A Radiated Emissions Requirements
EN 55024 and EN 61326-1 Immunity to Disturbance
RoHS per EU Directive 2011/ 65/ EC and WEEE per EU Directive 2002/ 96/ EC and China Electronic Industry
Standard SJ/ T11364-2006
GenICam XML Description File, Superset of the GenICam ™ Stand ard Featu res N aming Convention specification
V1.5, Camera Link Serial Com m unication: GenICam ™ Generic Control Protocol (GenCP V1.0)
Supported Industry Standards
GenICam™
Linea cameras are GenICam com pliant. They im plement a sup erset of the GenICam ™ Stand ard Features
Naming Convention specification V1.5.
This description takes the form of an XML device description file respecting the syntax defined by the
GenApi module of the GenICam™ specification. The camera uses the GenICam ™ Generic Control
Protocol (GenCP V1.0) to communicate over the Camera Link serial port.
