Page 9
>sf9
External NMEA baud detection enabled (9)
>
If you do not know the GPS baud rate, type SF9
(autodect).
>sf2
External NMEA diagnostics ON, pinging disabled
>NMEA External NMEA (3): Rx Buffer:$GPGGA,090307.2
NMEA External NMEA (3): Rx
Buffer:0,3237.182754,N,11713.812833,W,2,05,2.50,5.00
,M,0.00,M,000,0111*4A<CR><LF>$GPVTG,76.222,T,,,4.509,
N,8.350,K,D*70<CR><LF>$GPDB
T,23.083,f,7.036,M,138.498,F*31<CR><LF>$GPHDT,76.2,T*
06<CR><LF>
$GPGGA,090307.20,3237.182754,N,11713.812833,W,2,05,2.
50,5.00,M,0.00,M,000,0111*4A
$GPVTG,76.222,T,,,4.509,N,8.350,K,D*70
$GPDBT,23.083,f,7.036,M,138.498,F*31
$GPHDT,76.2,T*06
$GPGGA,090307.30,3237.182787,N,11713.812685,W,2,05,2.
50,5.00,M,0.00,M,000,0111*46
$GPVTG,75.202,T,,,4.679,N,8.665,K,D*76
$GPDBT,23.032,f,7.020,M,138.193,F*32
$GPHDT,75.2,T*05
$GPGGA,090307.40,3237.182822,N,11713.812539,W,2,05,2.
50,5.00,M,0.00,M,000,0111*45
Type SF2 to view the data coming from the GPS; This is
an example of a working GPS that is outdoors
providing fixes.
>sf2
External NMEA diagnostics ON, pinging disabled
$GPGGA,160832.989,,,,,0,0,,,M,,M,,*4E
$GPVTG,0.00,T,,M,0.00,N,0.00,K,N*32
If your GPS is indoors, you will see the following NON-
fully populated messages. However, they should have
the correct format and the checksum (*XX) at the end.
>sf2
External NMEA diagnostics ON, pinging disabled
NMEA External NMEA (3): Rx Buffer:$
<01>I<86><84>e<84><a6><a5><e5><a4><84>Z
NMEA External NMEA (3): Rx
Buffer:fX<a4>X<c7>$<a4><c5><c1>*<84><a6>w<c4><e4>DF<
86>I<c4><c2>D<c4><84><84>g@<83><01><81><c1><85><e5><a
4>*<c0><c6><e4>]<c5>-<e6><c
6><c6><c3><e0><c4><02>$<ac><c1><86>9)<95><b1>9<d5><d1
><cb><a9><8d><a9>MN<f5><a4>
7<08>{V<ab><af><c0>k'<fe>
NMEA ERROR: Second end character(\n) NOT found f
If the baud rate is incorrect you will NOT see the NMEA
messages but instead the following.
If the GPS baud rate is not close to your SF baud rate
setting, you may not even see this message.
