2.8.1.2 Analogue Output voltage
On pin 32 and pin 34 of the remote connector the analogue voltages
are scaled as the table below.
Temp Volts
30 1.76
20 2
10 2.67
0 3.29
-10 3.68
-20 4.06
-30 4.45
-40 4.87
-50 5.26
-60 5.66
-70 5.98
-80 6.4
-90 6.78
-100 7.17
-110 7.59
-120 8
-130 8.37
-140 8.74
-150 9.15
-160 9.52

=
3
.
17
−


25

The formula below can be used for the
calibration of the analogue output voltage
to temperature.
Table 8. Volts vs.
Temp Analogue
Output
Formulae 1. Volts vs.
Temp conversion
