Telemark Cryogenics Microprocessor Based Cryochillers
Page 5 of 63
Revision 1.0.7 October 2018
LIST OF FIGURES/ILLUSTRATIONS
Figures Page
1 Removing Unit from Transport Pallet 18
2 System Pressure Gauge 18
3 Services Panel 19
4 Water Flow requirements 20
5 Position of Hand Valves 21
6 Refrigerant Line Connections 21
7 Access Hand Valve 22
8 Refrigerant Manifold 22
9 Refrigerant Line Insulation 24
10 Metal “O” Ring Removal Tool 25
11 Main Isolator Wiring 26
12 Transformer Tapings 27
13 37 Way Amp Connector 30
14 Ethernet cable (crossed) 32
15 Network Connection Window 33
16 Network Properties 33
17 TCP/IP 34
18 TCP/IP Settings 34
19 TCP/IP GUI 36
20 Ethernet TCP/IP & RS232/485 Help 38
21 “cal2309” Setup Screen 39
22 Front Panel Push Buttons 42
23 Wait Start LCD Display 42
24 Pre-Cool LCD Display 43
25 Standby LCD Display 43
26 Cool LCD Display 43
27 Over Pressure Alarm LCD Display 48
28 DP High LCD Display 48
29 Emerson Compressor Front Panel 54
30 Emerson Compressor Internal Parts 54
