Call Progress Tones
LED Indications
Type ON cadence OFF cadence Remarks
Dial tone Continuous
Busy tone 0.5 Sec 0.5 Sec
Error tone 0.2 Sec 0.2 Sec
Distinctive tone 0.2 Sec 0.1 Sec
Incoming ring in
off-hook, before
dialling started
Confirmation tone
(for programming)
0.4 Sec 0.1 Sec 3 beeps
Rejection tone
(for programming)
0.4 Sec 0.1 Sec 2 beeps
RCPT LVL (Reception Level)
Indicates the
reception level
of the
iGATE
FCT
.
Green High reception.
Orange Medium reception
Red Low reception
Off Very low, or no reception at all
Note: To indicate proper activity of the channel while
idle, the LED turns off a few seconds every 15 sec-
onds of operation. During a call, the indication is fro-
zen at that which existed when the call started.
STATUS
Indicates the
channel oper-
ational status.
On The channel is handling a call.
Blinking (0.2S on, 0.2S off) - During ringing
Off The channel is idle.
Indications
Slow blinking (0.5S on, 0.5S off):
The channel is initializing following power up.
Fast blinking (0.1S on, 0.1S off):
No SIM card or an error has occurred in the PIN
code entry. The PIN code must be disabled or
the default PIN code 1234 must be entered.
Mostly on (0.5S on, 0.1S off)
Toll Restriction is activated
Special Indications
Blinking (0.3S on, 0.3S off)
During DTMF programming session
Blinking (0.2S on, 1S off)
During local PC session
POWER
Indicates the
status of the
power con-
nection.
On-the channel is powered on.
Off-the channel is powered off.
