Specifications
* Specifications are subject to change without notice
General Specifications
Mains Supply Voltage 100-240 VAC, 50-60 Hz
Current Consumption 0.5 A max
Operating temperature 0 °C to 45 °C
Physical dimensions 1U 19" shelf
Standards Full CE
Line Specifications (for each of the channels)
Line loop current 40 mA max
Line supply voltage - 48 VDC ± 10%
Line impedance 600 Ohm
Dial tone 400 Hz ± 1%
Ring generator 42 Vrms/25 Hz
Line signaling DTMF
Line connector (2W
TIP/RING)
RJ11-C (pin 2, 3- TIP, pin 4, 5- RING)
Data Port Specifications
Interface port RS232
Protocol AT Command Compatible
GSM Channel Specifications
Dual band GSM 900/1800Mhz or 850/1900MHz
Standards Type Approval CE mark.
GSM module WaveCOM Wismo 2D
Optional Features
Fax
Requires a data connection between the
iGATE FCT and a PC with Winfax
version 10 and up.
SMS
Requires a data connection between the
iGATE FCT and a PC running an
SMS application that supports Wave-
COM module.
Safety Standards
N°QUAEMC_EN. 15967C
Conforms to the EMC requirements of:
EN 301 489-1 V1.4.1: 2002; EN 301
489-7 V1 .2.1: 2002, R&TTE Directive
1999/5/EC and EMC Directive 89/336/
EEC Article 4.
N°QUAS AF_EN. 15967C
Conforms to the Safety requirements of:
EN/IEC 60950-1:200 1and AS/NZ
60950.1:2003
