User Manual E3
59300623 Rev.001
5.4.2018 13(20)
Forward path gain
[-26...0
dB, step 0.5 dB
]
Input slope
[-13...20 dB, step 0.5 dB
]
Interstage slope
[0...15 dB
,
step 1
dB]
Return path input gain
[
0 / -10 dB]
Return path gain
[-
20...0 dB, step 0.5 dB]
Enter button
Up / Down buttons
Ingress switch control
[0 dB
/ -6 dB / -50 dB]
Measured AC
RMS
voltage [V]
(Remote power model only)
Return path slope
[0...15 dB, step 0.5 dB]
PIN=0
ALARM CODES
:
E.INT = Internal error
E.PLU = Unknown plugin
E.PSU = Power supply failure
E.ACV = Remote AC voltage
E.TMP = Temperature
Display sleep: blinking
”E” = alarms, ”.” = no alarms
After
~
3 min
inactivity
Power save
[Off / On]
Local UI PIN setting
[0000 = disabled
]
Possible alarms
Each on separate row
Login screen
(displayed if PIN <>
0)
PIN OK
PIN<>0
Return Follows Forward
[
On /
Off]
PIN
NOK
Measured internal
temperature [°C]
Software version
Software version
3.6 and
below displays ”RET.A”
instead of ”RFF”:
Figure 5. E3 local user interface menu structure. Factory default values are in bold.
