User Manual E3
59300623 Rev.001
5.4.2018 8(20)
Features
Diplex and output modules
The E3 amplifier is delivered according to the ordering code.
The installed diplex filters (Figure 4 positions 3 and 5) must be new 1.2 GHz
types which are automatically detected by the software. The supported diplex
filter types listed in Table 1. It is also possible to order the amplifier without
diplex filters.
Diplex filters are automatically recognised by the software. "Unknown module"
alarm is activated if diplex filter type cannot be detected or if input diplex filter
frequency is different than output diplex filter frequency.
CXF065 65/85 MHz frequency split
65/85 MHz split with ingress blocker, passband f>10 MHz
65/85 MHz split with ingress blocker, passband f>18MHz
85/105 MHz frequency split
204/258 MHz frequency split
Table 1. Supported diplex filter types
Output modules are passive plug-ins used to control the outputs – see Table 2.
Functionality as output module
0 dB output module, 1 output in use
2/8 dB tap, 2 outputs in use
AC6114 2/12 dB tap, 2 outputs in use
1/16 dB tap, 2 outputs in use
Two-way splitter, 2 outputs in use
Table 2. Output modules with corresponding nominal attenuation values
