iRIS8 - Addressable Fire Alarm Panel – Installation Manual
6
1.3. General Specifications
The iRIS8 front panel consists of graphic TFT touch screen display (dimensions 800x480) and a light-emitting diode
(LED) indication. Separate operator and engineer passwords provide access to the functions of the panel.
Up to 8 loop controllers (iRIS8 TTE Loop expander) can be supplemented to the iRIS8 B outputs control modules, and
up to 4 to the iRIS8 S and iRIS8 Ext PCBs.
The system can be expanded by connecting up to 64 fire panels Teletek Electronics production (iRIS8 and IRIS/SIMPO
Repeater TFT) to the Ethernet network, using TCP/IP for communication between them.
iRIS8 has a built-in real time clock and calendar, allowing day and night time modes of operation. Switching over
between the day and night operation modes can be automatic or manual.
Events like FIRE, RESET, fault, etc., are saved in the memory in an event log-file. It contains the time and date, the
address of the device, the type (module, detector, sounder or periphery device), the name of the device, the zone, the
name of the zone, etc.
1.3.1 General Technical Specifications
• Loops - from 1 to 8 loops
• Up to 250 devices per one iRIS8 TTE Loop expander
• Max. number of devices - 2000
• Zone Number - 200 max.
• Zone Groups - 127 max.
• TTE Communication protocol
• Memory log for 10000 events
• Monitored relay outputs:
2, Sounder, 24V/1A
1, Fire Protection, 24V/0.1A
1, Fire, 24V/0.1A
1, Fault, 24V/0.1A
1, Sounder, 24V/1A
1, Fire Protection, 24V/0.1A
1, Fire, 24V/0.1A
1, Fault, 24V/0.1A
• Non monitored relay outputs (iRIS8 B and iRIS8 S):
o 4, Relay type (programmable), 10A@24VDC
o 1, Fire Protection (VdS 2540)
• Auxiliary output (terminals +24V and GND - see items 4.3.1 and 4.4):
1, Auxiliary, 24V/0.3A
1, Auxiliary, 24V/0.5A
• Specialized inputs for extinguishing (iRIS8 B and iRIS8 S):
o PrConf (Protection Confirmation) – Input for monitoring of signal “Confirmation for extinguishing started
in the site” sent by extinguishing control panel.
o FltPr (Fault Protection) – Input for monitoring of signal “Fault” sent by extinguishing control panel.
o AlConf (Alarm Confirmation) – Input for monitoring of signal “Alarm confirmation” sent by extinguishing
control panel.
• Display - 800/480 TFT
• Real time clock
• Up to 250 programmable Inputs/Outputs per panel
• Built-in RS485 and RS232 interface
• Comprehensive day/night mode facility
• 2 Steps of alarm levels (T1 and T2)
• Automatic synchronization of all loop sounders for better alarm signal
• Based on Windows graphical configuration utility via Ethernet or USB
• Simple Http monitoring utility
• Thermal printer (optional)
• PASO panel (optional)
• Multi-language support
• Easy software update
• Certified according EN 54-2/4, EN 54-13
ATTENTION: The total current consumption of outputs AUX, Sounder, Fire Protection,
Fire and Fault must not exceed 0.5A!
