Televes H30FLEX Sky User Manual

EN
7
Technical Specifications
Frequency
Range 50 - 880 MHz and 950 - 2200 MHz
Resolution 125 kHz
Tuning Frequency or channel
Input
Impedance 75Ω F-type connector
Sky Features
DTH Dish Aligment Standard Quad, WideBand, Smart, Hybrid LNB
DTH Dish Check Standard Quad, WideBand, Smart, Hybrid LNB
DTH Dish Logger Standard Quad, WideBand, Smart, Hybrid LNB
DTH Cable Logger Standard Quad, WideBand, Smart, Hybrid LNB
MDU Aligment Check Classic, Sky Q
MDU Dish Check Classic, Sky Q
MDU SAT1 Logger Classic, Sky Q
MDU Ports Logger Classic, Sky Q
MDU Bands Check Classic, Sky Q
MDU SAT2 Logger Classic, Sky Q
Spectrum Analyzer
Span 5, 10, 20, 50, 100, 200, 500 and Full span
Scale 5 and 10 dB/div
Auto and manual
reference level
Digital Measurements DVB-T
MPEG image
Modulations CFDM (QPSK, 16QAM, 64QAM)
Power 45-110dBuV (25-120dBuV opt.593235)
CBER 9.9E-2 - 1.0E-6
VBER 1.0E-3 - 1.0E-8
MER Up to 35dB
C/N Up to 40dB
Echoes
Constellation
Digital Measurements DVB-T2
MPEG image
Modulations COFDM (QPSK, 16QAM, 64QAM and 256QAM)
Power 45-110dBuV (25-120dBuV opt.593235)
LDPCBER 9.9E-2 - 1.0E-6
BCHBER 1.0E-3 - 1.0E-8
Link Margin Up to 30dB
MER Up to 35dB
C/N Up to 40dB
Echoes
Constellation
Digital Measurements DVB-S
MPEG image
Power 45-110dBuV (25-120dBuV opt.593235)
CBER 9.9E-2 - 1.0E-6
VBER 1.0E-4 - 1.0E-8
MER Up to 20dB
C/N Up to 20dB
Constellation
Digital Measurements DVB-S2
MPEG image
Modulations
QPSK, 8PSK
Power 45-110dBuV (25-120dBuV opt.593235)
Link Margin
Up to 10dB
MER
Up to 20dB
LDPCBER
9.9E-2 - 1.0E-6
BCHBER
9.9E-2 - 1.0E-8
Constellation
Analog Measurements
Level 25 - 125dBuV
V/A
C/N Up to 45dB
Features
Terrestrial channel
plans
CCIR, CCIR + LTE, OIRT, KBW, FCC, DAB, SIM
Satellite channel
plans
68E INTEL C, 68E INTEL, 42E TURK, 39E HELLAS,
33E EUTEL, 28E EUTEL, 28E ASTRA, 26E BADR,
25E EUTEL, 23E ASTRA, 21E EUTEL, 19E ASTRA,
16E EUTEL, 13E HOTB, 10E EUTEL C, 10 EUTEL,
9E EUTEL, 7E EUTEL, 4E ASTRA, 1W THOR5, 1W
THOR6, 5W EUTELC, 5W EUTEL, 7W NILE, 30W
HISPA, 48W AMZC, 48W AMAZ, SIM.
User channel plans
Units dBuV, dBmV, dBm
Preamp powering 13, 18, 24Vdc (max. current 475, 370, 140mA)
LNB powering 13, 18Vdc (max. current 475, 370mA)
LNB tone 22KHz
SCR (EN 50494) | dCSS
(EN 50607)
DiSEqC
