Hardware Specifications
Physical Interface
Please refer to the instructions on the label of the outer box to get the specification of your device.
Optical SC-connector with options:
- 100BASE-LX dual fiber single-mode WAN (Tx/Rx1310nm)
- 100BASE-BX single-strand single-mode WAN (Tx1310nm/Rx1550nm)
- 100BASE-FX dual fiber multimode WAN (Tx/Rx1310nm)
- 1000BASE-LX dual fiber single-mode WAN (Tx/Rx1310nm)
- 1000BASE-BX single-strand single-mode WAN (Tx1310nm/Rx1490nm)
100/1000BASE Optical SFP Optical convector
WLAN: 3 x detachable antennae (802.11n Fiber Optical Router only)
Ethernet: 4-port 10/100/1000M auto-crossover (MDI / MDI-X) Switch
Factory default reset button
WPS push button (802.11n Fiber Optical Router only)
Power jack
Power switch
Operating Environment
Operating temperature: 0 – 40°C
Storage temperature: -20 – 70°C
Humidity: 20 – 95% non-condensing
