The configuration, shown in Figure 6, is similar to Figure 10, “Typical Remote Headset Station.,” on page 21, except that each
channel is heard in a separate speaker. Make sure the internal DIP switches are set for binaural speaker operation as described
on “Monaural or Binaural Operation DIP Switches” on page 10. As in the previous example, a PA-KP local power supply is
required for each SPK2000 speaker, but is optional for the US-2002.
NOTE: For more information about cables, see Figure 15 on page 26.
FIGURE 12. Typical Remote Binaural Speaker Station.
