LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 21 of 149 2023-03-16
Not Subject to NDA
Mode Freq. Tx (MHz) Freq. Rx (MHz) Channels Tx-Rx Offset
LTE AWS – B4 1710 ~ 1755 2110 ~ 2155
Tx: 19950 ~ 20399
Rx: 1950 ~ 2399
400 MHz
LTE 850 – B5 824 ~ 849 869 ~ 894
Tx: 20400 ~ 20649
Rx: 2400 ~ 2649
45 MHz
LTE 2600 – B7 2500 ~ 2570 2620 ~ 2690
Tx: 20750 ~ 21449
Rx: 2750 ~ 3449
120 MHz
LTE 900 – B8 880 ~ 915 925 ~ 960
Tx: 21450 ~ 21799
Rx: 3450 ~ 3799
45 MHz
LTE 1800 – B9 1749.9 ~ 1784.9 1844.9 ~ 1879.9
Tx: 21800 ~ 2149
Rx: 3800 ~ 4149
95 MHz
LTE AWS+ – B10 1710 ~ 1770 2110 ~ 2170
Tx: 22150 ~ 22749
Rx: 4150 ~ 4749
400 MHz
LTE 700a – B12 699 ~ 716 729 ~ 746
Tx: 23010 ~ 23179
Rx: 5010 ~ 5179
30 MHz
LTE 700c – B13 777 ~ 787 746 ~ 756
Tx: 23180 ~ 23279
Rx: 5180 ~ 5279
-31 MHz
LTE 700PS – B14 788 ~ 798 758 ~ 768
Tx: 23280 ~ 23379
Rx: 5280 ~ 5379
-30 MHz
LTE 700b – B17 704 ~ 716 734 ~ 746
Tx: 23730 ~ 23849
Rx: 5730 ~ 5849
30 MHz
LTE 800 – B19 830 ~ 845 875 ~ 890
Tx: 24000 ~ 24149
Rx: 6000 ~ 6149
45 MHz
LTE 800 – B20 832 ~ 862 791 ~ 821
Tx: 24150 ~ 24449
Rx: 6150 ~ 6449
-41 MHz
LTE 1500 – B21 1447.9 ~ 1462.9 1495.9 ~ 1510.9
Tx: 24450 ~ 24599
Rx: 6450 ~ 6599
48 MHz
LTE 1900+ – B25 1850 ~ 1915 1930 ~ 1995
Tx: 26040 ~ 26689
Rx: 8040 ~ 8689
80 MHz
LTE 850+ – B26 814 ~ 849 859 ~ 894
Tx: 26690 ~ 27039
Rx: 8690 ~ 9039
45 MHz
LTE 700 – B28A 703 ~ 733 758 ~ 788
Tx: 27210 ~ 27510
Rx: 9210 ~ 9510
55 MHz
LTE 700 – B28 703 ~ 748 758 ~ 803
Tx: 27210 ~ 27659
Rx: 9210 ~ 9659
55 MHz
LTE AWS-3 – B66 1710 ~ 1780 2210 ~ 2200
Tx: 131972-132671
Rx: 66436-67335
400 MHz
LTE600 – B71 663 ~ 698 617 ~ 652
Tx: 133122-133471
Rx: 68568-68935
46 MHz
