Telit Wireless Solutions LE910C1-NS Hardware Design Guide

LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 24 of 149 2023-03-16
Not Subject to NDA
Mode Primary Diversity SIMO 3GPP
LTE 700PS – B14 -98.0 -99.5 -100.5 -93.3
LTE 700b – B18 -99.0 -100.0 -101.5 -96.3
LTE 800 – B19 -99.0 -99.5 -101.5 -96.3
LTE 800 – B20 -99.0 -99.0 -101.5 -93.3
LTE 1900+ – B25 -96.5 -98.5 -98.5 -92.8
LTE 850+ – B26 -99.0 -100.0 -101.5 -93.8
LTE 700 – B28A/B -98.5 -100.5 -101.5 -94.8
LTE AWS-3 – B66 -98.0 -99.0 -100.5 -95.8
LTE600 – B71 -98.0 -97.5 -100.5 -93.5
LTE TDD 2600 – B38 -98.0 -98.5 -100.5 -96.3
LTE TDD 1900 – B39 -98.5 -99.5 -101 -96.3
LTE TDD 2300 – B40 -97.0 -98.5 -99.5 -96.3
LTE TDD 2500 – B41M -97.0 -98.0 -99.5 -94.3
Table 6: sensitivity levels
Note: The sensitivity level has a deviation about +/- <2dB each model,
device and channel because the level shows typical value.
LTE level is measured at BW 10M
2.7.2. Output power
Typical values for Max output level are as follow:
 2G (GSM):
LB: Class 4(2W, 33dBm)
Class E2(0.5W,27dBm@EDGE)
HB: Class 1(1W, 30Bm)
Class E2(0.4W, 26dBm@EDGE)
 3G (WCDMA): Class 3(0.25W, 24dBm)
 TD-SCDMA: Class 3(0.13W, 21dBm)
 4G (FDD & TDD): Class 3(0.2W, 23dBm@1RB)
