LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 30 of 149 2023-03-16
Not Subject to NDA
PAD Signal I/O Function Type Comment
P1 VBATT_PA - Main Power Supply (RF Section) Power
P2 VBATT_PA - Main Power Supply (RF Section) Power
A2 GND - Ground
B13 GND Ground
D4 GND - Ground
E1 GND - Ground
E2 GND - Ground
E14 GND - Ground
F2 GND - Ground
G1 GND - Ground
G2 GND - Ground
G7 GND - Ground
G8 GND - Ground
G9 GND - Ground
H1 GND - Ground
H2 GND - Ground
H7 GND - Ground
H8 GND - Ground
H9 GND - Ground
J1 GND - Ground
J2 GND - Ground
J7 GND - Ground
J8 GND - Ground
J9 GND - Ground
K2 GND - Ground
L1 GND - Ground
L2 GND - Ground
M3 GND - Ground
M4 GND - Ground
M12 GND - Ground
N3 GND - Ground
N4 GND - Ground
