Telit Wireless Solutions ME910C1 Series User Manual

ME910C1 HW User Guide
1VV0301351 Rev.8 Page 16 of 99 2018-09-28
GNSS Section
R9 ANT_GNSS I
GNSS Antenna
(50 ohm)
RF
R7 GNSS_LNA_EN O
External GNSS LNA
Enable
CMOS 1.8V
Miscellaneous Functions
R13 HW_SHUTDOWN* I
HW Unconditional
Shutdown
1.8V Active low
R12 ON_OFF*/WAKE* I
Input command for power
ON and to wake from deep
sleep mode
1.8V Active low
R11 VAUX/PWRMON
O
Supply Output for external
accessories / Power ON
Monitor
1.8V
F14
FORCED_USB_BOO
T
I
Debug pin, connect to test
point
CMOS 1.8V
Active high,
internal PD
(100K)
Power Supply
M1 VBATT -
Main power supply
(Baseband)
Power
M2 VBATT -
Main power supply
(Baseband)
Power
N1 VBATT_PA -
Main power supply (Radio
PA)
Power
N2 VBATT_PA -
Main power supply (Radio
PA)
Power
P1 VBATT_PA -
Main power supply (Radio
PA)
Power
