ME910C1 HW User Guide
1VV0301351 Rev.8 Page 29 of 99 2018-09-28
General Design Rules
The principal guidelines for the Power Supply Design embrace three different design
steps:
the electrical design of the power supply
the thermal design
the PCB layout
4.3.1. Electrical Design Guidelines of the power supply
The electrical design of the power supply depends strongly from the power source where
this power is drained. We will distinguish them into three categories:
+5V input (typically PC internal regulator output)
+12V input (typically automotive)
Battery
4.3.1.1. +5V Source Power Supply Design Guidelines
The desired output for the power supply is 3.8V, hence there's not a big difference
between the input source and the desired output and a linear regulator can be used.
A switching power supply will not be suited because of the low drop out
requirements.
When using a linear regulator, a proper heat sink shall be provided in order to
dissipate the power generated.
A Bypass low ESR capacitor of adequate capacity must be provided in order to cut
the current absorption peaks close to the Module, a 100μF capacitor is usually
suited.
Make sure the low ESR capacitor on the power supply output rated at least 10V.
