ME910C1 HW User Guide

1VV0301351 Rev.8 Page 82 of 99 2018-09-28

PCB pad design

Non solder mask defined (NSMD) type is recommended for the solder pads on the PCB.

PCB

Copper

Pad

Solder Mask

SMD

(Solder Mask Defined)

NSMD

(Non Solder Mask Defined)
