Telit Wireless Solutions ME910C1 Series User Manual

ME910C1 HW User Guide
1VV0301351 Rev.8 Page 66 of 99 2018-09-28
CAT NB1 / Band 13 -113.6 -107.5
CAT NB1 / Band 18 -114.6 -107.5
CAT NB1 / Band 19 -114.2 -107.5
CAT NB1 / Band 20 -114.2 -107.5
CAT NB1 / Band 26 -114.2 -107.5
CAT NB1 / Band 28 -114.0 -107.5
GPRS / GSM850 -107.4 -104.0
GPRS / GSM900 -107.2 -104.0
GPRS / DCS1800 -109.6 -104.0
GPRS / PCS1900 -109.6 -104.0
Antenna requirements
The antenna connection and board layout design are the most important aspect in the full
product design as they strongly affect the product overall performances, hence read
carefully and follow the requirements and the guidelines for a proper design.
The antenna and antenna transmission line on PCB for a Telit ME910C1 device shall fulfil
the following requirements:
ME910C1-NA / ME910C1-NV
Item Value
Frequency range
Depending by frequency band(s) provided by the network
operator, the customer shall use the most suitable antenna for
that/those band(s)
Bandwidth
140 MHz in LTE Band 2
445 MHz in LTE Band 4
