ME910C1 is wide enough to ensure a dropless connection even during an 0.6 A
(LTE) or 2A (GSM) current peak.
• The protection diode must be placed close to the input connector where the power
source is drained.
• The PCB traces from the input connector to the power regulator IC must be wide
enough to ensure no voltage drops occur when an 2 A current peak is absorbed
(valid only for product supporting GSM mode).
• The PCB traces to the ME910C1 and the Bypass capacitor must be wide enough to
ensure no significant voltage drops occur. This is for the same reason as previous
point. Try to keep this trace as short as possible.
• To reduce the EMI due to switching, it is important to keep very small the mesh
involved; thus the input capacitor, the output diode (if not embodied in the IC) and
the regulator have to form a very small loop.This is done in order to reduce the
radiated field (noise) at the switching frequency (100-500 kHz usually).
• A dedicated ground for the Switching regulator separated by the common ground
plane is suggested.
• The placement of the power supply on the board should be done in such a way to
guarantee that the high current return paths in the ground plane are not overlapped
to any noise sensitive circuitry as the microphone amplifier/buffer or earphone
amplifier.
• The power supply input cables should be kept separate from noise sensitive lines
such as microphone/earphone cables.
• The insertion of EMI filter on VBATT pins is suggested in those designs where
antenna is placed close to battery or supply lines. A ferrite bead like Murata
BLM18EG101TN1 or Taiyo Yuden P/N FBMH1608HM101 can be used for this
purpose.
• The below figure shows the recommended circuit:
