ME910G1 HW Design Guide
1VV0301593 Rev.3 Page 57 of 97 2020-03-24
The following table shows the available GPIO on the ME910G1:
PAD
Signal
I/O
Output
Drive
Strength
Default State
C8
GPIO_01
I/O
1mA
INPUT PD (100K)
C9
GPIO_02
I/O
1mA
INPUT PD (100K)
C10
GPIO_03
I/O
1mA
INPUT PD (100K)
C11
GPIO_04
I/O
1mA
INPUT PD (100K)
B14
GPIO_05
I/O
1mA
INPUT PD (100K)
C12
GPIO_06
I/O
1mA
INPUT PD (100K)
C13
GPIO_07
I/O
1mA
INPUT PD (100K)
K15
GPIO_08
I/O
1mA
INPUT PD (100K)
L15
GPIO_09
I/O
1mA
INPUT PD (100K)
G15
GPIO_10
I/O
1mA
INPUT PD (100K)
5.8.1. Using a GPIO as INPUT
The GPIO pads, when used as inputs, can be connected to a digital output of another
device and report its status, provided this device has interface levels compatible with the
1.8V CMOS levels of the GPIO.
If the digital output of the device to be connected with the GPIO input pad of ME910G1
has interface levels different from the 1.8V CMOS, then it can be buffered with an open
collector transistor with a 47K pull up to 1.8V supplied by VAUX/POWERMON R11 pad.
