ME910G1 HW Design Guide
1VV0301593 Rev.3 Page 61 of 97 2020-03-24
6. RF SECTION
Bands Variants
See section 2.2.
TX Output power
See section 2.5.
RX Sensitivity
See section 2.6.
Antenna requirements
The antenna connection and board layout design are the most important aspect in the full
product design as they strongly affect the product overall performances, hence read
carefully and follow the requirements and the guidelines for a proper design.
The antenna and antenna transmission line on PCB for a Telit ME310G1 device shall fulfil
the following requirements:
Depending by frequency band(s) provided by the network
operator, the customer shall use the most suitable antenna for
that/those band(s)
250 MHz in LTE Band 1
140 MHz in LTE Band 2, PCS1900
170 MHz in LTE Band 3, DCS1800
445 MHz in LTE Band 4
70 MHz in LTE Band 5, GSM850
80 MHz in LTE Band 8, GSM900
47 MHz in LTE Band 12
41 MHz in LTE Band 13
60 MHz in LTE Band 18
60 MHz in LTE Band 19
71 MHz in LTE Band 20
145 MHz in LTE Band 25
80 MHz in LTE Band 26
62 MHz in LTE Band 27
100 MHz in LTE Band 28
490 MHz in LTE Band 66
