Technical Specification
Load capability:
Maximum load - 4lbs 6oz ( 2kg)
Counting resolution - 1 banknote/coin
Dimensions:
T-i
X
including Money Platform
Length 11.4” (291 mm)
Width 6.0” (152 mm)
Height 6.5” (166 mm)
Weight:
T-i
X
- 2lbs 2oz (0.98 kg)
Battery - 1.7oz (0.049 kg)
Power supply:
Power adapter
Input to suit country of use.
Output 5V AC 1.2A
Power connection
6.5 mm reverse jack on the rear panel.
Power indication
Green LED on the lower front face illuminates
on power from the power supply or PC USB
connection.
Battery:
Removable, rechargeable Li-ion
Duration: Over 12 hours constant use.
Charging time: 4 hours using the power
supply provided.
External interfaces:
USB - A
For upgrading product software
Serial (optional)
For connection to a Tellermate supplied printer
USB - B (optional)
For connection to PC for data transfer
Ethernet (optional)
Ethernet Adaptor FCC68 cat 5, 8-way
connector to network
Display:
Full Graphic LCD
3.0” x 1.6” (77 mm x 41 mm)
240 x 128 pixel resolution
Adjustable backlight and contrast
Soft touch keys:
3 ‘soft key’ fast access keys
Navigation D pad and confirmation
On/Off, Home, Clear Entry, End Count
Environmental requirements:
Temperatures
Storage: -4
o
F to 140
o
F (-20
o
C to 60
o
C)
Operating: 40
o
F to 104
o
F (5
o
C to 40
o
C)
Humidity
All times: 0-95% RH non-condensing
