From underneath, place by hand the 6 new screws
with spring washers for securing the hub assembly.
View of the 6 screws under stator (gearbox side).
Check again that all output coils (black and red) of
the 10 coils, are well located in the notches.
Place again the pressure washers on top of the
coils and check that they are well located.
