1.3.7.2 3.3-3.8 GHz, 2 Ports 65º Dual Slant (2x2)
1.3.7.3 3.3-3.8 GHz, 2 Ports 90º Dual Slant (2x2)
Table 11: ANT, BS, 3.3-3.8 GHz, DS, Sec.65°, 16.5dBi Minimum (P.N. 300644) Specifications
Item Description
Frequency Band (MHz) 3,300–3,800
Number of Elements 2
Polarization Linear, +/-45°
Gain 16.5dBi +/- 0.5dB
VSWR 1.5:1 (max)
Azimuth Beamwidth (degrees) 65 +/-5
Elevation Beamwidth (degrees) 6 +/-1
Maximum Power (W) 50
Cross-polarization Discrimination (dB) -15
Front-to-Back Ratio (dB) >25
Isolation Between Ports (dB) >25
RF Interface Impedance (Ohm) 50
Lightning Protection DC grounded
RF Connectors 2 x N-type jacks
Mounting Fully adjustable pipe mount (1.63” to 4.5” pipe)
with 0–15° down tilt
Dimensions (mm) 711 x 171 x 90
Weight (Kg) 2.6 (excluding mounting kit)
Regulatory Compliance RoHS Compliance
Table 12: ANT, BS, 3.3–3.8 GHz, DS, Sec.90°, 15.5dBi Minimum (P.N. 300645) Specifications
Item Description
Frequency Band (MHz) 3,300–3,800
Number of Elements 2
Polarization Linear, +/-45°
Gain 15.5 dBi +/- 0.5 dB
VSWR 1.5:1 (maximum)
Azimuth Beamwidth (degrees) 85 +/-5
Elevation Beamwidth (degrees) 6 +/-1
Maximum Power (W) 50
