Chapter 1 - System DescriptionSpecifications
Chapter 1: System Description
Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BreezeCOMPACT System ManualBreezeCOMPACT System Manual
33
1.3.8 BMAX-4M-GPS Receiver Specifications
Table 15: BMAX-4M-GPS Receiver, Mechanical and Electrical Specifications
Cross-polarization Discrimination (dB) >15
Front-to-Back Ratio (dB) >30
Isolation between Ports (dB) >30
Return Loss (dB) >15
Upper Sidelobe Suppression (dB) >18
RF Interface Impedance (Ohm) 50
Lightning Protection DC grounded
RF Connectors 4 x N-type jack
Electrical Downtilt 4° (fixed)
Mounting Adjustable mounting kit (optional) for 50–115mm pole, with +2° to
-10° tilt range
Dimensions (mm) 720 x 260 x 55
Weight (Kg) 7 (excluding mounting kit)
Item Description
Dimensions 8.8 x 10.4 x 16 cm
Weight 0.38 Kg
Power Source 12 VDC from the BTS
Power Consumption 2W maximum
Connector RJ-45
Table 14: ANT-DDP-90°-3.3-3.8 GHz (P.N. 300719) Specifications (Continued)
Item Description
