Chapter 3: Operation and Administration
Sector Menu
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BreezeCOMPACT System ManualBreezeCOMPACT System Manual
66
3.6 Sector Menu
In the current release, the unit supports a single sector.
The Sector menu includes the following options:
Sector Definition
Radio Cluster
Antenna Association
3.6.1 Sector Definition
The Sector Definition menu enables you to view or modify the informational parameters described below.
3.6.1.1 Name
The sector name. An optional descriptive string of up to 32 printable characters.
The default is null (an empty string).
3.6.1.2 Heading
The sector heading (the center angle of the sector), in degrees.
An optional descriptive value in the range from 0 to 359.
The default is 0.
3.6.1.3 Width
The planned sector coverage, in degrees.
A value in the range from 0 to 359.
The default is 0.
3.6.2 Radio Cluster
Radio Cluster is a virtual object enabling definition of the bandwidth, frequency and transmit power parameters. The values
configured for these parameter determine the bandwidth and frequency of relevant BS(s) and the Tx power of all relevant
Radio Head Tx ports. The Radio Cluster concept simplifies configuration of these parameters, especially in installations
using dual-carrier operation (One Sector, Dual Carrier topology, which is not supported in the current release).
The Radio Cluster menu enables you to view or modify the parameters described below.
