2.5.3 Configuring Antenna Associations
Using the Monitor Program
1 Select Sector > Antenna Association > Add. You are prompted to configure the following parameters:
 RF Port Number: Enter 1.
 Antenna Number: Enter the relevant Antenna Number as configured in the Antenna menu.
 Antenna Port Number: Enter the relevant Antenna Port Number.
2 Repeat the Antenna Association configuration for RF Port Numbers 2 to 4.
Using the Management System
1 In the Association section of the Sector 1 screen, click Add Association and enter the relevant Antenna Number and
Antenna Port Number for RF Port 1.
2 Repeat the process for RF Port Numbers 2 to 4.
3 Click Apply.
2.5.4 Applying the Configuration
To apply the changes, reset the unit as follows:
 In the Monitor program, select BTS > Unit Control > ShutDown Operation > Update and then select the Reset
option for the Shutdown Operation parameter.
 In the management system, select the Equipment > Chassis screen. In the Shut Down Operation section, select the
Reset option for the Shut Down Type parameter and click Apply.
