Chapter 1 - System DescriptionSpecifications
Chapter 1: System Description
Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BreezeCOMPACT System ManualBreezeCOMPACT System Manual
32
1.3.7.4 3.3-3.8 GHz, 4 Ports 65º Double Dual Slant (4x4)
1.3.7.5 3.3-3.8 GHz, 4 Ports 90º Double Dual Slant (4x4)
Table 13: ANT-DDP-65°-3.3-3.8 GHz (P.N. 300736) Specifications
Item Description
Frequency Band (MHz) 3,300–3,800
Number of Elements 4
Polarization Linear, 2 x +/-45°
Gain 18 dBi
Azimuth Beamwidth (degrees) 65
Elevation Beamwidth (degrees) 7
Maximum Power (W) 150
Cross-polarization Discrimination (dB) >15
Front-to-Back Ratio (dB) >30
Isolation between Ports (dB) >30
Return Loss (dB) >15
Upper Sidelobe Suppression (dB) >18
RF Interface Impedance (Ohm) 50
Lightning Protection DC grounded
RF Connectors 4 x N-type jack
Electrical Downtilt 0° (fixed)
Mounting Adjustable mounting kit (optional) for 50–115mm pole, with +2° to
-10° tilt range
Dimensions (mm) 720 x 260 x 55
Weight (Kg) 7 (excluding mounting kit)
Table 14: ANT-DDP-90°-3.3-3.8 GHz (P.N. 300719) Specifications
Item Description
Frequency Band (MHz) 3,300–3,800
Number of Elements 4
Polarization Linear, 2 x +/-45°
Gain 17 dBi
Azimuth Beamwidth (degrees) 90
Elevation Beamwidth (degrees) 7
Maximum Power (W) 150
