Telrad CPE9000 - Installation and Connectivity

LTE Outdoor CPE | User Manual P. 16
SIM status
○○●
○○○
Green
Steady ON SIM Detected
Blinking when
On-hook
PUK / PIN Code
OFF No SIM Detected
LTE Status LED :
When CPE is power on, each LED
indicates each link status
Link Status 1
○○○
● ○○
Red
Steady ON SINR < 9dB
Link Status 2
○○○
●●○
Red/
Yellow
Steady ON
9dB < SINR <
16dB
Link Status 3
○○○
●●●
Red/
Yellow/
Green
Steady ON 16dB < SINR
Installation
● Selecting a Location: LTE Outdoor CPE should be pole-mounted outdoors and aligned
so its antenna faces the nearest LTE eNodeB. When selecting a suitable location for the
unit, consider these guidelines:
• Place LTE Outdoor CPE as high as possible to achieve the best possible link quality.
• Place the LTE Outdoor CPE away from power and telephone lines.
• Avoid placing LTE Outdoor CPE too close to any metallic reflective surfaces.
• Be sure to ground LTE Outdoor CPE with an appropriate grounding wire (not
included) by attaching it to the grounding screw on the unit and to a good ground
connection.
