TABLE 9 – COOLING PERFORMANCE DATA* – 150 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 105.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1868.0 1206.8 1868.7 974.5 1865.6 760.5
71 1752.2 1375.5 1748.4 1142.5 1742.5 918.9 1741.1 705.6
67 1656.4 1498.3 1639.3 1287.1 1634.5 1076.7 1636.3 862.4 1638.0 648.0
62 1616.4 1588.0 1531.2 1446.0 1506.4 1266.5 1504.8 1056.0 1503.2 845.5
34500
75 1883.2 1240.3 1882.6 996.9 1880.8 770.2
71 1767.8 1415.5 1763.8 1169.6 1759.4 935.1 1758.4 712.4
67 1681.7 1532.1 1654.6 1331.5 1649.1 1100.5 1650.3 875.4 1651.5 650.3
62 1646.2 1624.0 1558.8 1492.0 1520.8 1305.6 1518.7 1076.6 1516.7 847.6
37000
75 1898.3 1273.8 1896.6 1019.3 1896.1 779.9
71 1783.3 1455.6 1779.2 1196.8 1776.4 951.3 1775.6 719.1
67 1707.0 1565.9 1669.8 1376.0 1663.6 1124.3 1664.3 888.4 1665.0 652.5
62 1676.0 1659.9 1586.5 1538.0 1535.2 1344.7 1532.7 1097.2 1530.3 849.8
39500
75 1913.5 1307.2 1910.5 1041.6 1911.3 789.6
71 1798.9 1495.6 1794.6 1223.9 1793.3 967.5 1792.9 725.8
67 1732.3 1599.7 1685.1 1420.5 1678.2 1148.1 1678.3 901.4 1678.5 654.8
62 1705.9 1695.8 1614.1 1584.0 1549.5 1383.9 1546.7 1117.9 1543.8 851.9
42000
75 1928.6 1340.7 1924.5 1064.0 1926.6 799.3
71 1814.5 1535.7 1810.0 1251.0 1810.3 983.7 1810.1 732.6
67 1757.6 1633.5 1700.3 1465.0 1692.7 1171.9 1692.4 914.5 1692.0 657.0
62 1735.7 1731.7 1641.8 1630.0 1563.9 1423.0 1560.7 1138.5 1557.4 854.0
44500
75 1941.4 1376.0 1934.9 1085.4 1934.9 806.4
71 1825.1 1559.7 1819.7 1282.9 1819.0 1002.8 1818.7 738.8
67 1774.9 1664.5 1708.8 1498.6 1703.3 1195.3 1700.6 927.5 1697.9 659.8
62 1756.1 1751.0 1658.9 1643.7 1573.5 1450.8 1569.8 1162.8 1566.2 874.9
47000
75 1954.3 1411.3 1945.2 1106.8 1943.1 813.5
71 1835.8 1583.8 1829.5 1314.8 1827.8 1021.9 1827.3 745.1
67 1792.2 1695.6 1717.4 1532.3 1714.0 1218.8 1708.9 940.6 1703.7 662.5
62 1776.5 1770.3 1675.9 1657.3 1583.0 1478.5 1579.0 1187.1 1575.1 895.7
49500
75 1967.1 1446.6 1955.6 1128.1 1951.4 820.6
71 1846.4 1607.9 1839.2 1346.6 1836.5 1040.9 1835.8 751.4
67 1809.5 1726.7 1725.9 1565.9 1724.6 1242.2 1717.1 953.7 1709.6 665.3
62 1796.9 1789.5 1693.0 1671.0 1592.6 1506.3 1588.2 1211.4 1583.9 916.6
52000
75 1979.9 1481.9 1965.9 1149.5 1959.6 827.8
71 1857.1 1632.0 1848.9 1378.5 1845.3 1060.0 1844.4 757.7
67 1826.7 1757.8 1734.4 1599.5 1735.3 1265.6 1725.4 966.8 1715.5 668.0
62 1817.3 1808.8 1710.1 1684.6 1602.1 1534.0 1597.4 1235.7 1592.8 937.4
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
