TABLE 9 – COOLING PERFORMANCE DATA* – 150 TON MODEL (CONT’D)
AIR ENTERING
EVAPORATOR
COIL
OUTDOOR AMBIENT TEMPERATURE 115.0°F
ENTERING DRY BULB TEMPERATURE
CFM
WET
BULB (°F)
92.0°F 86.0°F 80.0°F 74.0°F 68.0°F
TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH TMBH SMBH
32000
75 1770.1 1167.1 1773.0 937.2 1770.3 742.0
71 1665.2 1334.7 1658.9 1094.0 1645.6 875.2 1645.2 665.1
67 1594.8 1434.1 1559.1 1250.9 1553.5 1041.7 1556.3 827.9 1559.0 614.0
62 1559.6 1535.1 1481.3 1407.8 1433.8 1230.8 1430.3 1020.1 1426.8 809.4
34500
75 1783.9 1202.3 1784.6 959.9 1782.1 748.2
71 1677.1 1374.7 1671.3 1127.0 1659.5 893.5 1660.7 673.0
67 1616.4 1475.9 1572.6 1294.2 1566.4 1064.3 1568.4 840.0 1570.5 615.8
62 1584.9 1563.0 1502.6 1436.8 1445.2 1268.1 1442.2 1044.6 1439.1 821.2
37000
75 1797.7 1237.5 1796.1 982.6 1793.8 754.5
71 1689.0 1414.7 1683.7 1160.0 1673.5 911.7 1676.2 680.9
67 1638.0 1517.7 1586.1 1337.5 1579.3 1086.9 1580.6 852.2 1582.0 617.5
62 1610.2 1590.9 1523.9 1465.8 1456.7 1305.4 1454.1 1069.2 1451.5 832.9
39500
75 1811.5 1272.8 1807.7 1005.3 1805.6 760.7
71 1700.9 1454.7 1696.0 1193.0 1687.4 930.0 1691.6 688.8
67 1659.6 1559.5 1599.6 1380.7 1592.1 1109.5 1592.8 864.4 1593.5 619.3
62 1635.5 1618.7 1545.2 1494.7 1468.1 1342.7 1465.9 1093.7 1463.8 844.7
42000
75 1825.3 1308.0 1819.2 1028.0 1817.3 766.9
71 1712.8 1494.7 1708.4 1226.0 1701.3 948.2 1707.1 696.7
67 1681.2 1601.3 1613.1 1424.0 1605.0 1132.1 1605.0 876.6 1605.0 621.0
62 1660.8 1646.6 1566.5 1523.7 1479.5 1380.0 1477.8 1118.2 1476.1 856.4
44500
75 1838.5 1343.2 1827.6 1048.5 1823.1 772.3
71 1724.7 1520.5 1718.5 1253.0 1711.8 962.9 1715.6 701.6
67 1695.5 1625.8 1618.6 1454.5 1614.4 1152.4 1609.7 887.6 1605.0 622.8
62 1680.1 1668.8 1582.9 1548.9 1489.2 1404.0 1486.5 1135.1 1483.7 866.2
47000
75 1851.6 1378.3 1835.9 1069.0 1828.9 777.7
71 1736.6 1546.3 1728.7 1280.0 1722.2 977.6 1724.1 706.5
67 1709.8 1650.2 1624.1 1485.0 1623.9 1172.7 1614.4 898.6 1605.0 624.5
62 1699.4 1691.0 1599.2 1574.0 1498.9 1428.0 1495.1 1152.0 1491.4 875.9
49500
75 1864.8 1413.5 1844.3 1089.5 1834.6 783.0
71 1748.5 1572.2 1738.8 1307.0 1732.7 992.3 1732.6 711.4
67 1724.0 1674.6 1629.5 1515.5 1633.3 1192.9 1619.1 909.6 1604.9 626.3
62 1718.7 1713.3 1615.6 1599.2 1508.5 1452.0 1503.8 1168.8 1499.0 885.7
52000
75 1877.9 1448.7 1852.6 1110.0 1840.4 788.4
71 1760.4 1598.0 1748.9 1334.0 1743.1 1007.0 1741.0 716.3
67 1738.3 1699.1 1635.0 1546.0 1642.7 1213.2 1623.8 920.6 1604.9 628.0
62 1738.0 1735.5 1631.9 1624.3 1518.2 1476.0 1512.4 1185.7 1506.6 895.4
* Rated performance is at sea level. Cooling capacities are gross cooling capacity.
