Tenda A9 User Manual

10
Web UI Features
③ Open a browser on your smartphone (take Safari as an example here), type the default
login domain name re.tenda.cn or default login IP address 192.168.0.254 into the address
bar, and click Go.
④ When the extender’s web UI appears, select the WiFi name (SSID) you want to extend,
and click Next.
⑤ Enter the WiFi password of the selected WiFi name (if any), and click Finish.
Tips
If you don’t want to set up the extender’s
WiFi name and password to the same as
those of the base station, uncheck the
option before Set up the extender’s
WiFi name and password to the same
as those of the Base Station, customize
the extender’s WiFi name and password,
and then click Finish.

Tenda A9 Specifications

General

Type	Network transmitter & receiver
Ethernet LAN data rates	- Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Antenna gain level (max)	3 dBi
Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA-PSK, WPA-TKIP, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Product color	Grey, White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	47.7 mm
Width	56 mm
Height	111 mm
