Tenda A9 User Manual

24
Web UI Features
⑥ Unplug the extender and move it to a new location that is about halfway between your
router and the area with a poor router WiFi signal. Observe the LED indicator on the
extender to choose an optimum extending location.
Tips
 You can also log in to the extender’s web UI to check the WiFi signal strength
(40%~79% is the optimum extending location).
 To minimize signal interference, keep the extender away from Bluetooth devices,
microwaves, refrigerators, and so on.
The steps are complete! Enjoy your WiFi! Your extender’s WiFi name and password may be
one of the following.
 Be default
The extender’s WiFi name and password are the same as those of your router. For
example, if your router’s WiFi name is Tenda_666666 and WiFi password is 00000000,
as a result, your extender’s WiFi name and password are Tenda_666666 and 00000000
respectively.

Tenda A9 Specifications

General

Type	Network transmitter & receiver
Ethernet LAN data rates	- Mbit/s
Maximum transfer distance	- m
Antenna type	External
Antennas quantity	2
Antenna gain level (max)	3 dBi
Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA-PSK, WPA-TKIP, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Product color	Grey, White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	47.7 mm
Width	56 mm
Height	111 mm
