Tenda F9 User Manual

Parameters
Parameters
Description
Network Mode
Network Mode
 11b: It indicates that clients compliant with 802.11b can connect to the router. The
maximum wireless rate is 11 Mbps.
 11g: It indicates that clients compliant with 802.11g can connect to the router. The
maximum wireless rate is 54 Mbps.
 11b/g: It indicates that clients compliant with the 802.11b or 802.11g protocol can
connect to the router. The maximum wireless rate is 54 Mbps.
 11b/g/n: It indicates that clients compliant with the 802.11b, 802.11g, or 802.11n
protocol can connect to the router. The maximum wireless rate is 600 Mbps.
Wireless
Channel
It specifies the operating channel of the WiFi network. A channel different from nearby
channels are recommended for less interference and better wireless transmission
efficiency. You can use a third-party tool to identify the channels different from nearby
channels.
Wireless
Bandwidth
It specifies the bandwidth of the operating channel of the WiFi network. Change the default
setting only when necessary.
 Auto: It specifies that a router can switch its channel bandwidth between 20 MHz and
40 MHz based on the ambient environment.
 20MHz: It indicates that the channel bandwidth of a router is 20MHz.
 40MHz: It indicates that the channel bandwidth of a router is 40MHz.
Anti-interference
By default, the anti-interference function is disabled.
If smart phones can search many WiFi signals nearby, you’d better enable this function.

Tenda F9 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Modulation	16-QAM, 64-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channel bandwidth	40 MHz
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	600 Mbit/s
Product type	Tabletop router
Product color	White
LED indicators	System, WAN, WLAN, WPS
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	-95 dBm, -74 dBm, -72 dBm, -62 dBm, -70 dBm, -73 dBm, -86 dBm, -90 dBm
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11b)	21.5 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11g)	17.5 dBmW
Equivalent Isotropically Radiated Power (EIRP) (@IEEE 802.11n)	15 dBmW
Ethernet LAN (RJ-45) ports	4
Flash memory	2 MB
Internal memory	16 MB
Processor model	Realtek
Output current	1 A
Output voltage	9 V
Power source type	DC
Power consumption (typical)	1.98 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Frequency band	2.4 - 2.4835 GHz
Antenna gain level (max)	6 dBi
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Browser supported	Internet Explorer 5.0, Firefox 1.0
Windows operating systems supported	Windows 2000
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	171.3 mm
Height	36.4 mm
